Blog 11 - Market forms of Steel



Structural Steel is mainly used for transferring the building loads. Structural Steel is available in market under various options, depending upon its intended use and implication in the building structure.

Market steel

Market steel is available in standard sizes and specifications. According to these specifications, the structural part of the building is designed.

Here are the most common market forms of steel

Angle sections

  • L shaped equal or unequal angle sections
  • The sections are manufacture intact 90 degrees angles
  • e.g. 50x50x8 mm (depth x depth x thickness)
  • Used in frames



Channel Sections

  • C- shaped sections
  • Two equal flanges extending from one side with a longer web
  • Used in structural member of steel structures
  • Available Indian market sections are ISJC, ISLC, ISMC
  • (J-junior L-lightweight M-medium weight)

Corrugated Sheets

  • Corrugated steel is formed by passing the sheets through grooves
  • These corrugated sheets are galvanised iron sheets
  • Preferably used in roof covering

Flat Bars

Flat bars are panel- like steel forms available in thicknesses like 3mm to 40mm and 10mm to 400 mm wide

It is used in steel grill work for windows and gates

I-Sections

  • Rolled steel joists/ beams with two flanges and a web. e.g. 75x50 mm at 61 N
  • Similar beams with wide flanges are called as H-sections. E.g. 150x150 mm at 27N

Plates

  • Rolled steel flat beams of thicknesses varying from
    5mm to 50mm
  • Used to connect steel beams for extension of length and in steel trusses as tensile members



Ribbed Tor steel bars

  • Steel bars circular in cross section, ribbed on the surface
  • Manufactured by cold twisting of hot rolled steel in a controlled manner

Round Bars

  • Steel billets with circular cross-section of diameter varying from 5mm to 50mm
  • Used in reinforcement in steel grillwork and in concrete sections

Square Bars

  • Steel billets with square cross-section
  • Used in steel grillwork, windows, gates.
  • Available in sizes of 5mm x 5mm to 25mm x 25mm

T-Sections

  • Flange and web with unequal sides, bulbs at the bottom edge of the web.
  • Available in 20mm x 20mm x 3mm at 9 N/m (depth x depth x thickness)
  • Used in steel roof sections

Other market forms of steel include

  • Acute
  • Obtuse
  • Rail sections
  • Trough sections
  • Z- sections

As the session came to an end, we had a small discussion on Architecturally Exposed Structural Steel. The basic purpose of AESS is to fulfill the aesthetic and structural requirement of any structure. Some requirements that AESS is needed to have are shear and moment resistance, achieving a balance or symmetry, and meet the target under economic constraints. The opportunities found in the practice of AESS are Collaborative efforts of people from various fields, witnessing architecture of a different scale and language and much more. AESS and the standard steel differ in its function, surface treatment & appearance, joinery details and scale.



-  Janani Venkateswaran

No.of words - 475
